Covet Aluminum battens - Urbanik Surfaces

Wood Look Batten Cladding

Photorealistic wood look and metal finishes offer a maintenance-free, dimensionally accurate, lightweight alternative to timber and steel.

Offering designers an array of decorative screening and batten cladding and screwless installation applications, Covet aluminum cladding is designed to endure the outdoor elements of the environment while maintaining a natural wood aesthetic and textured feel. Designers can achieve the look of natural wood in a non-combustible, lightweight, sustainable, and durable aluminum cladding with a beautiful Japanese quality and finish.

Covet Batten Series Sets The Bar For Aluminium Wood Look Cladding

Offering freedom of choice, our range of wood-look aluminum systems and finishes provide several architectural possibilities, from creating a standout feature wall to enveloping your entire exterior. The most natural, true-to-life timber aesthetic, the Japanese-crafted finishes are truly convincing in an interior setting while possessing excellent exterior-grade properties that are designed to withstand the harsh outdoors and aggressive coastal environments.

Kabebari Ever Art Wood® – two part concealed fix battens

Ever Art Wood ® is surface a treated Aluminum that looks like wood, and is often textured like wood. It is a lightweight, dimensionally accurate, virtually maintenance free material that is rigorously tested for UV and fire standards. The Kabebari batten is a simple yet elegant split batten system with a base for affixing to a frame or surface and a top that snaps onto the base concealing the screws inside.

The Kabebari batten offers 4 variants, each option offers characteristics tailored to suit a specific design aesthetic or application.

Kabebari Standard
Best suited for privacy screening, decorative batten screens, operable screens, or to span glazing.
The base plate is visible from side profile.

Kabebari Surface
Recommended for surface mounting directly to substrates. The batten cover clips in to fully shroud the mill-finished base plate. Upgrade to a fully wrapped finish is also available.

Kabebari Slimline
With a refined, low-profile, Slimline are most suited for intimate interior spaces; garage door applications where lightweight, low clearance battens are a consideration, or where a lighter aesthetic is desired.

Kabebari Suspend
A super light-weight, floating batten ceiling system that is practical, easy to install, with a cavity space for acoustic infills. Any Kabebari or Koshi batten can be affixed to T-sections suspended from steel ceiling rods.

Kabebari Standard

The base plate on the Kabebari Standard is visible on 3 sides of the batten profile. The visible depth of the base plate from a side profile varies and is dependent on the batten dimension selected.

Most suited to applications that span glazing, and the main aspect is viewed from the batten front and back, or where the base plate is upward facing, and partially exposed, such as pergola style applications.

The standard Kabebari batten is fully wrapped on all 4 sides.

Kabebari Cladding – Kogarana
Two Section Concealed Fix
1″ x 1 “

Kabebari Cladding – Rectangle

Two Section Concealed Fix
1½” x ¾”
1¼” x 2”
1¼” x 3¼”
2” x 4”
2” x 6”

Kabebari Cladding – Square
Two Section Concealed Fix
1¼” x 1¼”
1½” x 1½”
2” x 2”

Kabebari Cladding – Oki
Two Section Concealed Fix
4″ x 4″

Kabebari Cladding – Plank
Two Section Concealed Fix
4” x ½”

Kabebari Cladding – Nami Plank
Two Section Concealed Fix
Wave plank profile
4” x ½”

Kabebari Cladding – Achi
Two Section Concealed Fix
Achi profile
1½” x 1½”

Kabebari Cladding – Domu
Two Section Concealed Fix
3½” x 1⅝”

Kabebari Surface

The batten cover of the Surface fully shrouds the base plate. The profile has no visible seams when viewing the side profile and is most suited to applications where one face of the batten is not visible, or a minimal seam, real timber aesthetic is desired.

Only the cover section (3 sides) of the Kabebari Surface is wrapped. The base plate is supplied in mill-finished aluminium as standard. A wrapped base plate can be supplied as an optional upgrade.

Kabebari Surface | Low Profile

Two Section Concealed Fix
Low profile batten
1½” x ¾”
2” x 1″

Kabebari Surface – 30×30
Two Section Concealed Fix Surface Mounted Batten Cladding
Square Profile
1¼” x 1¼”

Kabebari Surface – 40×40
Two Section Concealed Fix Surface Mounted Batten Cladding
Square Profile
1½” x 1½”

Kabebari Surface – 50×50
Two Section Concealed Fix Surface Mounted Batten Cladding
Square Profile
2” x 2”

Kabebari Surface – 30×50
Two Section Concealed Fix Surface Mounted Batten Cladding
Rectangle Profile
1¼” x 2”

Kabebari Surface – 30×85
Two Section Concealed Fix Surface Mounted Batten Cladding
Rectangle Profile
1¼” x 3¼”

Kabebari Surface – 50×100
Two Section Concealed Fix Surface Mounted Batten Cladding
Rectangle Profile
2” x 4”

Kabebari Surface – 50×150
Two Section Concealed Fix Surface Mounted Batten Cladding
Rectangle Profile
2” x 6”

Kabebari Slimline

The Slimline design options are dimensionally smaller, sitting less proud from a structure, and characterised by a raised base plate for a shadow line effect that creates the illusion of depth.

Most suited for installations where weight restrictions are a consideration such as in garage installations, or where real estate is limited, or a lightweight aesthetic is desired.

The slimline batten covers are wrapped to 3 sides. The base plate is available in mill-finish aluminium only.

Most suited for applications where a small batten aesthetic with low profile is desired or a very light-weight batten profile is essential.

Kabebari Slimline Rectangle Batten Cladding
Two Section Concealed Fix
Low profile batten
1¼” x ½”
1¼” x ¾”

Kabebari Slimline Batten Cladding – Mikadzuki
Two Section Concealed Fix
Curved profile
1¾” x ¾”

Kabebari Slimline Batten Cladding – Round
Two Section Concealed Fix
Semi-circle profile
single
¾” x ¾”
double
1¾” x ¾”

Kabebari Batten Cladding – Curved
Two Section Concealed Fix
Slightly curved profile
w/ square edge
1¼” x ¾ ”

Kabebari Suspend

Super light-weight, floating batten ceiling system that pairs with any of the Kabebari batten range or the Koshi Standard Hollow Sections. It is a practical, easy to install, suspended ceiling batten system that allows for acoustic infills. Battens are affixed to supplied plain powder-coated T-sections, which are suspended from steel ceiling rods.

Note: Requires 3rd party Rondo Rods for suspension.

NOTE:
All dimensions are width x depth unless otherwise indicated.
Batten lengths are available in standard 4m or 6m lengths and can be cut to length.
For large quantities battens lengths can be made to order to reduce wastage and minimise cost.
Allow 8-12 weeks lead time as our timber look aluminium cladding is made to order in Japan.
Refer to individual product guides for further details.
